Description

Specifications

Material: Aluminum Alloy
Size Range Guide: 4-30mm
Dimensions:135x52x35mm
Weight: Approximately 286g/box
Blade: Outer Diameter 18mm, Inner Diameter 5mm, Thickness 3mm
Applicable: Suitable for forks, handlebars, seatposts, compatible with aluminum, steel, and titanium alloys (excluding carbon fiber).

Features

1. Integrated Forged Aluminum Alloy: Sturdy, durable, high accuracy, and long lifespan.
2. Dual Roller Positioning: Stainless steel axis ensures quick and precise positioning, allowing flexible rotation.
3. Compact Design: Includes a filer and spare blade for versatile use.
4. Large Range Compatibility: Compatible with a wide range of pipe diameters.

Application

1. Install the headset with the fork, adjust the handlebar height, and tighten the stem.
2. Mark the excess fork edge with a marker.
3. Cut the pipe 8mm below the marked line.
4. Adjust to ensure full contact between the fork and the rollers.
5. Rotate the handle gradually, tighten step by step, and advance with each step until you hear a "click" sound indicating the section has been cut.
6. Use the triangular file to sharpen the cut section; proceed to the next step only after filing.
7. The cut section is now sharp and ready.
